Focus on DTF & UV DTF inkjet printing solution
Personalized Badges & Medals | Made with UV6090 Flatbed Printer
● Smart Visual Positioning – CCD camera system enables automatic alignment for irregular shapes and pre-cut materials
● Universal Material Compatibility – Prints directly on glass, acrylic, wood, leather, PVC, and diverse rigid/flexible substrates
● High-Definition Output – Epson I3200-U1 printhead delivers detailed prints up to 720x3600 DPI resolution
● Efficient UV Curing – LED air-cooled system ensures fast, energy-saving ink fixation
● Automatic Height Sensing – Infrared measurement adjusts printhead clearance for varied material thickness
● Integrated Ink Management – Three-head carriage with capping station maintains printhead performance and reliability
● Universal Material Compatibility – Prints directly on glass, acrylic, wood, leather, PVC, and diverse rigid/flexible substrates
● High-Definition Output – Epson I3200-U1 printhead delivers detailed prints up to 720x3600 DPI resolution
● Efficient UV Curing – LED air-cooled system ensures fast, energy-saving ink fixation
● Automatic Height Sensing – Infrared measurement adjusts printhead clearance for varied material thickness
● Integrated Ink Management – Three-head carriage with capping station maintains printhead performance and reliability
5.0
design customization
Please fill out the form below to request a quote or to request more information about us. Please be sure to upload customized requirement documents or pictures, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Please fill out the form below to request a quote or to request more information about us. please be as detailed as possible in your message, and we will get back to you as soon as possible with a response. we're ready to start working on your new project, contact us now to get started.
Operation Process
01
Import the processed pictures into the computer
02
CCD visual positioning system, Automatic infraredheight measurement
03
Printing
04
Finished product display
Applicable
c9344537ebbcb9d15bdde28f8c3c1ff1eb6b05fb3bec0-ZXq2
f32da7ce78f34a4c46b3b8e27b0d479b1c1bf767b4721-cQ4a
ea359fceaf1f44173e2125ebb422694f861a04241f182-Km0o
dfe96782be4a5f735c995b2c49b13d38daf6e53711052-Sj41
b6feefdcc5fdf62785f434df1da545283be73e612725a-Mxjh
4c621e32aac70a48a8a6069efab05205898b3e1c7315d-QpSD
The Advantage Of DTF UV Printer
Air Switch
Base plate and damper heating
Carriage Ink Capping Station
CCD CAMERA
CMYK+W+V
Waste ink barrel
Emergency Stop
Functional Buttons
High Quality Driving Wheel
High-quality platform
HIWIN Linear Guide
Ink Tank Alarm
Maximum Print Size 600x900mm
Simple and clear key board
UV LED Air cooling
Automatic Infrared Height Measurement
Product parameter
|
Model |
BF-UV6090 |
Print head |
3pcs Epson I3200-U1 |
||||
|
Resolution |
6pass: 720*1200DPI |
8pass: 720*1800DPI |
12pass: 720*2400DPI |
||||
|
Speed |
4-8m²/h |
Color |
CMYK+W+Varnish |
||||
|
Print width |
600mm*900mm |
INK |
UV ink |
||||
|
Operation |
Temperature:15°C~30°C |
Enviroment |
Humidity:40%-60% |
||||
|
Power |
220V 10A 400W |
System |
Windows10 or Above |
||||
|
Machine size |
1700*1545*1315mm(L*W*H) |
Packing size |
1880*1625*870mm(L*W*H) |
||||
|
Weight |
240KG/320KG |
lmage format |
Bitmap,Tiff,Jpeg,Eps,Pdf |
||||
